Cortizo 4700
More about Cortizo 4700 Sliding Door
Trusted manufacturers since 2000
Professional Installer Network
Quick Supply
Made in the UK
Exceptional Quality Control
Knowledgeable Family Run Business
Bespoke Complex Products Fabricated
Cortizo’s 4600 lift and slide door completely transforms the look of any space, while exhibiting some of the best thermal efficiency on the market. The system is perfect for enclosing large spaces while providing maximum light, with an ultra-smooth opening action and perfect sash sliding over a stainless steel track.
- U-value of 0.9 W/m²K
- 110mm standard section and minimalist solution of 50mm
- Possibility of large sash dimensions ideal for enclosing large spaces
- Maximum glazing thickness of 55mm
- Maximum sash width of 3300mm and height of 3300mm
- Maximum sash weight of 400kg
Technical Specification
- Maximum glazing thickness
55 mm - Opening possibilities
Sliding of 2, 3, 4 & 6 sashes
Possibility of 1 rail (1 sash + 1 fixed light)
& 3 rails - Sections
Frame 160.6 mm - 3 rails 251 mm
Sash 70 mm - Profile thickness
Door 2.0 mm - Polyamide strip length
Frame 35 mm / Sash 24 mm - Maximum dimensions/sash
Width (L) = 3,300 mm
Height (H) = 3,300 mm - Maximum weight/sash
400 kg
Please consult regarding maximum weight and dimensions for other opening types
Finishes
Possibility of dual colour systems
Colour powder coating (RAL, mottled and rough)
Wood effect powder coating
Anti-bacterial powder coating
Anodised
Colours
White aluminium frame colour finish sample.
Matt white aluminium frame colour finish sample.
Matt brown aluminium frame colour finish sample.
Jet black aluminium frame colour finish sample
Grey aluminium frame colour finish sample.
Gloss white aluminium frame colour finish sample.
Gloss off white aluminium frame colour finish sample.
Dark red aluminium frame colour finish sample.
Dark grey aluminium frame colour finish sample.
Dark green aluminium frame colour finish sample.
Dark brown aluminium frame colour finish sample.
Dark blue aluminium frame colour finish sample.
Cream aluminium frame colour finish sample.
Black aluminium frame colour finish sample.
Anthracite grey aluminium frame colour finish sample.
Airforce grey aluminium frame colour finish sample.
Glass
Unglazed aluminium window frame with angled top.
Standard self-clean glass panel with clear finish.
Standard toughened glass panel with clear finish.
Clear solar control glass panel for improved comfort and energy efficiency.
Self-cleaning glass panel designed to break down dirt and reduce cleaning frequency.
Self Clean Solar Control panel combining dirt-repelling and heat-reducing technology.
Satin obscure glass panel with smooth frosted finish.
Laminated security glass panel with clear finish.
Hardware
White 9010
Light silver
Grey 7016
Dark silver
Custom ral
Black 9005
Brochure
Gallery
FAQs About Cortizo 4600 Sliding Doors at Direct Trade Windows
What makes the Cortizo 4600 Plus Lift & Slide different from standard sliding doors?
Unlike standard sliding doors, the lift-and-slide mechanism raises the door slightly off the track for smooth, effortless movement and a tight seal when closed, improving insulation and security.
How large can the panels be?
Each sash can be up to 3,300 mm wide and 3,500 mm high, with a maximum weight of 400 kg, allowing for very large glazed areas without compromising performance.
How energy-efficient is it?
With Uw values from just 0.65 W/m²K (depending on glazing), the Cortizo 4600 Plus offers excellent thermal insulation, helping reduce heating and cooling costs.
What weather performance ratings does it have?
It’s tested to Class 4 air permeability, Class E750 water tightness, and Class C5 wind resistance for reliable all-weather performance.
Can it be customised?
Yes — choose from a range of powder-coated RAL colours, wood-effect finishes, anodised options, and dual-colour combinations.
What glazing options are available?
It can accommodate glazing up to 65 mm thick, including double or triple-glazed units for enhanced energy efficiency and sound insulation.
Where is it most commonly used?
Popular in contemporary homes, extensions, and commercial buildings where large, open views and high performance are required.
Is it suitable for corners without a central post?
Yes — the system offers a 90° corner opening option without a mullion, perfect for uninterrupted panoramic views.
